A better solution for bulk filling

Fig 1. Initial situation: secondary caries underneath old composite filling on the first mandibular molar

Dr Christoph Hüskens explains how the dual-curing principle can be a major advantage compared with the existing thin-flowing bulk composites presently available on the market

In this case, a young patient was provided with a direct posterior tooth restoration using the dual-curing, medium-viscous bulk composite Fill-Up! (with antibacterial zinc oxide additive) and an approximate 2 mm covering layer of the established hybrid composite SYNERGY D6 (by COLTENE).


Composite restorations in the posterior tooth region have for decades proven to be a suitable alternative to metallic fillings such as amalgam, which many patients refuse these days. During this time, the material group of composites has been continuously improved. The new generations of bonding agents, with less polymerisation shrinkage and greater abrasion resistance, together with modern layer techniques, are now the standard in dental practice.

Nonetheless, composite restorations in the posterior region still remain quite time-consuming. To meet the needs of many dental practitioners and for the purposes of simplification, particularly with regards to the time-consuming layer technique in the less aesthetics-oriented posterior region, the dental industry has for some time now started developing a variety of bulk-fill composites. To date there have been two groups, the bulk-fill composites with low viscosity and the bulk-fill materials with high viscosity. Fill-Up!, which is presented here, can be classified as a new third group of bulk-fill materials, with medium viscosity with good abrasion stability.

The expression “bulk fill” actually implies “filling in a single step”. This means quick and simple application and finishing, less polymerisation stress and good durability at lower technique sensitivity with the known bonding agents, as well as adequate bonding to enamel and dentine. The maximum curing depth of 4-5 mm remains a limiting factor with many bulk-fill materials, both for low and high viscosity composites.

However, the Fill-Up! material used here is a dual-curing bulk composite. This allows the application of layer thicknesses of more than 5 mm in a single step, without any impairment in curing of the entire increment. This is an advantage in the case of approximal surfaces in the posterior region, for example, if deep root caries is also present in a Class II. Reliable chemical curing is assured after 3 minutes (including processing time), it is not essential to measure whether a layer thickness of between 4-5 mm can be attained. By using additional shortlight-curing, the polymerisation process of the upper layers can be accelerated and the filling processed directly. Slight post-darkening is generally observed in chemically curing materials. With the Fill-Up! Universal material used here, the final shade is achieved after 24 hours and is comparable to the shade VITA A2/A3.

Only a few patients demand highly aesthetic restorations in the poorly visible posterior region, so the disadvantage of different shaded fillings can be ignored after the first molar in both the maxilla and the mandible. For example, this includes patients presenting in the dental practice for the replacement of old amalgam fillings or also patients who want shorter treatment sessions.

This also applies to the treatment of children, which will not be addressed in this case study.

Using the dual-curing Fill-Up! Bulk composite it is possible to facilitate Class I and Class II fillings quickly and easily. The material used demonstrates excellent flow behaviour here, which is extremely helpful, especially for deep Class II fillings.

An approximate 2 mm thick covering layer of hybrid composite, here SYNERGY D6, is not essential, but was chosen in this case for occlusal design purposes and improved aesthetics, as well as approximal contact-point design. This also reinforces the mechanical stability of the entire filling.

Highly viscous bulk-fill materials with a limited range of shades can be used for modelling, but the poorer adaptation behaviour at this viscosity can lead to the known problems of primary marginal gaps or air bubbles. Therefore, this material group is not the optimal solution per se.

When performing a cover-layer filling, it is possible to fill the cavity in two steps when using the Fill-Up! Material applied here. This also represents clear savings in time compared with the usual four to five increments for conventional methacrylate-based hybrid composites and the corresponding longer and additive exposure times. The S.P.E.C 3 polymerisation lamp by COLTENE usedhere, takes five seconds at a performance setting of 1600 mW/cm2. Add to this the manufacturer’s reference that the recommended exposure time should not be exceeded to keep the shrinking stress as low as possible. In addition, it is also recommended to adhere to the curing time of two minutes in case of very deep cavities (over 4-5 mm) to avoid adhesion of the material to the matrix.

Using Fill-Up! for Class II cavities

The new Fill-Up! bulk composite lends itself for use on the young patient with approximal secondary caries on tooth 36 mesial (Fig 1).

The cavity is prepared after drying with the dental dam (Elasti-Dam, COLTENE). Applying the known rules for the acid etching technique, Fill-Up! was quasi under-filled to approximately 2 mm below the preparation margin before applying the covering layer of SYNERGY D6. Finishing and polishing was performed with DIATECH products by COLTENE.


Every time we want to use a good flowing composite for larger cavities in our practice, without having to accept the known disadvantages of shrinking stress, then the Fill-Up! bulk composite is an excellent complement to our present range of composite materials (for example, SYNERGY Flow or SYNERGY D6). The dual-curing principle is a major advantage compared with the existing thin-flowing bulk composites presently available on the market, for example, Filtek Bulk Fill by 3M ESPE.

The conventional maximum layer thickness of 4-5 mm can certainly be exceeded without drawbacks in daily routine. A good restoration can also be ensured if the increment lies in the so-called “light shadow” of the polymerisation lamp. The material properties described here can also prove useful when filling a root-treated tooth and result in quicker restoration of the tooth.

With the Fill-Up! bulk composite by COLTENE, one can be assured that the dual-curing material is cured completely in every part of the filling after three minutes (including processing time). The offered product is convenient and simple to handle, due to the different diameters of the mixing tip attachments.

In addition, the filling with bulk and hybrid composite represents a clear advantage in terms of time saved when compared with conventional filling methods consisting of several small increments. And finally, the application of a covering layer of SYNERGY D6 results in good aesthetics as well as contact point design.

From nought to high gloss in no time

Universal composite BRILLIANT EverGlow is distinguished by long-lasting gloss stability

It is vital in restorative dentistry to have a high-performance, reliable material for an aesthetically attractive and quick result. Ultra-modern composites offer excellent blending and can be quickly processed with no complications.

Permanent gloss in next to no time

The specially-developed BRILLIANT EverGlow from COLTENE represents an entirely new quality of composite. Due to the intelligent composition with special fillers, the sub-micron hybrid universal composite offers an exceptionally uniform and smooth surface. Dentists can achieve highly aesthetic results in next to no time. The versatile filling material also excels through its extremely durable gloss stability.

BRILLIANT EverGlow comprises seven universal and two transparent shades. Unique blending properties ensure the shades integrate harmoniously into the existing dental arch. Elaborate layering can also often be dispensed with as a natural restoration is already achieved with the single use of a universal-shade.

An additional enamel shade can help those with relatively translucent teeth.

Smooth consistency for good wetting ability

The smooth BRILLIANT EverGlow composite allows better handling for dentists and can be applied easily into cavities of all classes. The dimensionally stable material can be modelled without haste until polymerisation. Due to its good wetting capacity, it offers excellent adhesion to bonded tooth surfaces without sticking to the instruments. The abrasion-resistant material is suitable for anterior and posterior restorations.

Dentists at this year’s BDIA Showcase can experience the stunning quality and convenient handling of the innovative filling materials from the COLTENE research laboratories (Stand G45).


Figures 1-6

Figures 7-11
