Getting the whole picture

Dr Laura Fee gives an overview on the use of panoramic radiographs in general dental practice

Radiation regulations stipulate that all radiographs must be justified and reported in the dentist’s notes and that a quality assurance programme must be implemented in each practice to optimise the image quality:

  • Justification: the practitioner must obtain a net benefit from exposing the patient to radiation. The dentist should supply details of the patient’s radiographic history.
  • Optimisation: Radiation doses must be kept as low as reasonably achievable.
  • Reporting: All radiographs must be reported. Dates, causes and repeat exposures should be documented for any radiographs of no diagnostic value.
  • Quality Assurance: Factors such as correct positioning, contrast and processing must be checked. A feedback mechanism helps improve the image quality and in identifying any deficiencies.

Striking the balance between limiting the radiation

exposure to the patient versus the likely diagnostic benefit is a constant challenge for dentists. Although new panoramic units have incorporated dose–limiting features, the faster film has resulted in a failure to significantly reduce the radiation dose to the patient. Most digital panoramic systems require increased exposure factors compared with conventional methods1. Surprisingly, the comparative diagnostic yield with conventional film radiography has been shown to be similar2.

New patients

It has been found that 63 per cent of general dentists routinely screen new adult patients using panoramic radiography3. There is, however, increasing evidence of poor image quality of panoramics in primary care settings4. It is imperative that the patient be correctly positioned and, for film–based radiography, the best processing techniques must be employed. Every dental practice should adhere to a strict quality assurance programme to maximise the diagnostic value of panoramic images.

Disturbingly, it has become routine in some practices to take panoramic radiographs for all new patients. Research has shown that bitewings and periapical radiographs are better for diagnosing caries, periodontal and periapical pathology5. Worryingly however, a large number of dentists use only panoramic radiographs to assess common dental pathosis6.

Furthermore, it has been found that some dentists routinely use panoramics to screen for clinically unsuspected pathology5. Taking radiographs routinely in the absence of any clinical signs or symptoms cannot be justified unless implant treatment is planned7. It is worth remembering that asymptomatic dental pathology has a remarkably low prevalence.

In cases of gross neglect, it may be expeditious to take panoramic radiographs to help identify teeth requiring a more detailed radiographic examination. Also, it is often appropriate to take a panoramic radiograph for patients in a hospital setting before oral surgery under general anaesthesia8.

Edentulous patients

In cases where the clinical exam reveals an abnormality, such as a retained root, an intraoral radiograph of the site is the best radiographic examination.

Late mixed dentition

If, at 11 years old, the canines cannot be palpated, either buccally or palatally, an intraoral radiograph would be appropriate. Early diagnosis of a misplaced canine is of importance to the child’s orthodontic outcome.

Radiographically the preferred means of localisation is parallax. This is the apparent displacement of an image relative to the image of a reference object. It is caused by a change in the angulation of the X–ray beam9. The reference object is usually the root of an adjacent tooth. The image of the tooth that is the most far away from the X–ray tube moves in the same direction as the tube, whereas the image of the tooth closer to the X–ray tube moves in the opposite direction to the tube (SLOB rule – Same Lingual Opposite Buccal). A panoramic and anterior occlusal radiograph are commonly used in these cases giving approximately a 60 degree tube shift.

A limited field–of–view CBCT examination may be needed where the prognosis of the lateral incisor is questionable on a conventional radiograph due to resorption by a misplaced canine.

Deciduous molars

If the second deciduous molars are retained when other successional teeth have erupted, an appropriate field–limited panoramic radiograph can be used. However, in the case of a single second deciduous molar being retained, an intraoral image may suffice.

Permanent molar

A grossly carious first molar will normally require a field–limited panoramic radiograph to assess the prognosis of the other first molars and to confirm the presence of permanent successors. An orthodontic opinion is advisable where the loss of one or more first molars is necessary.


Radiography is extremely beneficial in orthodontic treatment planning. However, research indicates that it is excessively used within the specialty. Although routine screening of children is inappropriate, the use of selection criteria has been highly effective in determining children likely to benefit from a radiographic examination10. Research consistently highlights the limited effect radiography has on altering orthodontic diagnosis and treatment plans11.

If a specialist orthodontic opinion is necessary, it is imperative that any radiographic images accompany the referral letter once an orthodontic opinion is being sought. However, general dentists should whenever possible leave the choice of radiograph to be taken by the specialist once an orthodontic opinion has been deemed necessary from their clinical exam.

Oral surgery

Panoramic radiographs are frequently used in the assessment of third molars before their surgical removal, however this does not need to be carried out at the initial examination12 Routine radiography of unerupted third molars is not recommended10. Panoramic radiographs provide information about the distance to the lower border of the mandible and the anatomy of the inferior dental canal. It must be remembered that panoramic radiography does not provide an accurate indication of a close relationship with the inferior dental canal.

In surgical cases where there is a suggestion of a close relationship between the root apices and the mandibular canal, either a second radiograph using a different projection geometry13 or a localised CBCT examination should be performed if this is likely to result in a change of the surgical management. However, it should be noted that currently there is insufficient evidence to support the use of routine CBCT in these cases and there is no evidence to indicate any improvement in outcomes when CBCT is used.

For situations such as apicectomy, root removal or enuclation of cysts, an intraoral radiograph may be adequate for treatment planning.


Intraoral radiography provides ample diagnostic information when assessing simple dental trauma.

Panoramic radiographs are the first line for imaging mandibular fractures. 14 However, poor panoramic image quality has been shown to be a major problem in general practice which reduces diagnostic accuracy15. Additional imaging is often required for diagnosing condylar fractures.16

Panoramic radiography has limited ability to detect mid–facial fractures. If there is clinical evidence of a bone fracture it is best to defer a complete radiographic examination until the patient is at the hospital.

Temporomandibular joint problems

The panoramic radiograph shows an image of the mandibular condyles and is often the first choice as an imaging technique for patients with TMJ symptoms. However, research has proven that, in patients with TMJ symptoms, panoramic radiography provides little or no information that influences the diagnosis or management in most cases examined17.

The majority of patients with signs and symptoms related to the TMJ are suffering with myofacial pain/dysfunction or internal disc derangements. Condylar abnormality is not seen in myofacial pain/dysfunction and only occasionally seen with internal disc derangement. Radiography is not recommended for patients with clicking in the absence of other signs/symptoms18.

Radiographic examination is also indicated where there is evidence of progressive pathology such as trauma, change in occlusion, mandibular shift, sensory motor alterations or change in range of movement.

Periodontal assessment

There is no clear evidence to support any recommendations regarding the frequency of radiographs taken for periodontal reasons. Dentists should always use radiographs taken for caries diagnosis to assess the periodontal hard tissues. Bitewings provide information about bone levels without the need for an additional radiation dose.

If a patient has generalised pocketing of 4–5mm and little or no recession, horizontal bitewings are recommended. These may be supplemented by intraoral periapicals for selected anterior teeth but only if it is likely to change the management of the patient.

Assessment of all teeth and their periodontal support can be obtained with the use of a panoramic radiograph alone, a panoramic radiograph with supplementary periapical radiographs, or a complete series of periapical radiographs. When determining which radiographic technique to use, consideration should be given to the clinical presentation, the required image quality and the relative dose–benefit based on the equipment available.

Panoramic radiographs with supplementary periapicals potentially provide a radiation dose advantage over a full–mouth series of periapicals. However, the dose from periapical radiographs may be less than that of a panoramic if periapicals are restricted to affected teeth.

A periapical radiograph using a paralleling technique is indicated if a periodontal/endodontic lesion is suspected.

If a patient has pocketing of 6mm or more, vertical bitewings are recommended, supplemented by intraoral periapical views using the paralleling technique at sites where alveolar bone image is not included. These may be supplemented by intraoral periapicals for selected anterior teeth, but only if this is likely to change management of the patient.

The decision to take further radiographs to assess changes to the periodontium over time should be taken on a case–by–case basis. Radiographs should be secondary to the clinical exam and taken when they have the potential to change the patient’s management.

When assessing alveolar bone levels, digital radiography may offer improved measurement accuracy when compared with film radiographs. CBCT is not indicated as a routine method of imaging periodontal bone support. However, where CBCT images include the teeth, care should be taken to check for periodontal bone levels.

Radiographs in implant dentistry

Currently there is little evidence on which to formulate guidelines for the use of radiographs in implant dentistry. Radiography is crucial in implant dentistry for the assessment of bone and reviewing their long–term maintenance. Radiographs are needed to assess existing natural teeth and the healing of extraction sockets. Osseointegration cannot be visualised on routine radiographs, however, a peri–implant radiolucency may suggest fibrous tissue encapsulation warning the dentist of future implant failure. A baseline radiograph is recommended at the end of the prosthodontic phase of treatment. This helps to assess marginal bone levels for future reference and verifies the correct connection of the implant components.

A radiograph one year later can be beneficial in recognising changes in bone levels. In cases of multiple implant placements, a good panoramic radiograph with magnification markers can provide excellent information. The surgeon must of course consider the potential magnification and patient positioning errors.

It is extremely important that the surgeon can assess the inferior dental canal, mental foramen along with the canal’s complex morphology in order to avoid damage during implant placement. Panoramic radiographs are considered acceptable for implants placed in the posterior mandible, providing a minimum 2mm to 4mm safety margin superscript19 from the canal and bone width is maintained.

It should be remembered that panoramic images are magnified by up to 30 per cent and that such magnification can vary significantly at different locations within the same radiograph. In order to prevent dimensional distortion, patients must be positioned accurately. It may be useful to employ reference objects, such as ball bearings in a baseplate at the planned implant site. In the case of an edentulous patient, they may leave in their acrylic dentures to allow for more accurate positioning.

Where cross–sectional information is appropriate, CBCT techniques may be employed to formulate treatment plans or to construct guides for surgical implant placement and pre–fabrication of prostheses.

A radiographic review at one, three or up to five years is advisable to verify stable bone levels or to detect progressive bone loss. Radiographic evidence of bone levels is recommended if signs such as increased probing depths, bleeding, exudate or mobility are present.

The choice of radiographic technique used in implant dentistry is further complicated by the experience of the surgeon. An experienced practitioner may feel that they have adequate information from a two–dimensional imaging technique, whereas a less experience practitioner may feel more confident with the additional information gained by a CBCT image. As with any radiological investigation, dentists must prioritise dose limitation as the principle factor in deciding which imaging modality to prescribe.

Guidelines and recommendations for 3D imaging

The European Association for Osseointegration has made the following recommendations for CBCT imaging in dental implant therapy20:

1. Bone defect considerations (extensive bone augmentation)

2. Sinus floor augmentation/elevation considerations

3. Evaluation of intra–oral donor sites

4. Special techniques (e.g. zygoma etc)

5. Computer–assisted treatment planning and placement of dental implants

6. Postoperative complications (specifically nerve damage).

With the increased use of CBCT imaging in dental practice, clinicians must be made aware that the patient radiation dose associated with CBCT imaging are higher than those of conventional radiographic techniques. Strategies which optimise exposure, such as Field of View reduction to the region of interest must be utilised in keeping with the ALARA principle of keeping radiation exposure As Low As Reasonably Achievable.


It should be emphasised that the use of radiography is secondary to a clinical exam and full mouth periodontal assessment. All existing radiographs should be used as much as possible. Previous radiographs may be very useful in assessing the rate of disease progression.

Many studies have been published on the diagnostic accuracy, sensitivity and specificity of panoramic radiology compared to intraoral radiographic examinations. These highlight that panoramic imaging is inferior in the detection of the most common dental diseases. Panoramic radiography is therefore not indicated as a routine radiographic technique for general dental practice.

A panoramic radiograph should be prescribed on a case–by–case basis only in specific situations after careful consideration of the patient’s clinical history and examination.

About the Author

Dr Laura Fee graduated with an honours degree in dentistry from Trinity College, Dublin. During her studies, she was awarded the Costello medal for undergraduate research on cross–infection control procedures. She is a member of the Faculty of Dentistry at the Royal College of Surgeons and, in 2013, she completed the Certificate in Implant Dentistry with the Northumberland Institute of Oral Medicine and has since been awarded the Diploma in Implant Dentistry with the Royal College of Surgeons, Edinburgh. Laura is currently completing the Certificate in Minor Oral Surgery with the Royal College of Surgeons, England. She has also been involved with undergraduate teaching in the School of Dentistry, Belfast where she has an honorary oral surgery contract.


1. Hart D, Hillier MC, Wall BF. National reference doses for common radiographic. Fluoroscopic and dental x–ray examinations in the UK. Br J Radiol 2009; 82:1–12

2. Hintze H, Wenzel A, Frydenberg M. Accuracy of caries detection with four storage phosphor systems and E–speed radiographs. Dentomaxillofac Radiol 2002; 31:170–5

3. Davies C, Grange S and Trevor MM. Radiation protection practices and related continuing professional education in dental radiography. Radiography 2005;11:255–61

4. Helminen SE, Vehkalati M, Wolf J and Murtomaa H. Quality evaluation of young adults’ radiographs in Finnish public oral health service. J Dent 2000; 28: 549–55

5. Pepelassi EA, Tsiklakis K and Diamanti–Kipioti A. Radiographic detection and assessment of the periodontal endosseous defects. J Clin Periodontol 2000; 27:224–30

6. Rushton VE, Horner K, Worthington HV. Screening panoramic radiology of adults in general dental practice: radiological findings. Br Dent J 2001; 190:495–501

7. Brooks SL, Cho SY. Validation of a specific criterion for dental radiography. Oral Surg Oral Med Oral Pathol 1993; 75:383–6

8. National Radiological Protection Board. Guidance notes for dental practitioners on the safe use of X–ray equipment. NRPB. London: Department of Health; 2001

9. Mason C, Papadakou P, Roberts G. The radiographic localization of impacted maxillary canines: a comparison of methods. Eur J Orthod 2001; 23(1): 25–34.

10. Hintze H, Wenzel A, Williams S. Diagnostic value of clinical examination for the identification of children in need of orthodontic treatment compared with clinical examination and screening pantomography. Eur J Orth 1990; 12:385–388

11. Atchinson KA, Luke LS, White SC. An algorithm for ordering pretreatment orthodontic radiographs. Am J Orthod Dentofac Orthop 1992;102:29–44

12. Scottish Intercollegiate Guidelines Network. Management of unerupted and impacted third molar teeth. Edinburgh:SIGN; 1999

13. Flygare L and Ohman A. Preoperative imaging procedures for lower wisdom teeth removal. Clin Oral Invest 2008;12:291–302

14. Guss DA, Clark RF, Peitz T, Taub M. Pantomography vs mandibular series for the detection of mandibular fractures. Acad Emerg Med 2000;7:141–145

15. Markowitz BL, Sinow JD, Kawamoto HK Jr, Shewmake K, Khoumehr F. Prospective comparison of axial computed tomography and standard and panoramic radiographs in the diagnosis of mandibular fractures. Ann Plast Surg 1999; 42:163–169

16. Wilson IF, Lokeh A, Benjamin CI, Hilger PA, Hamler DD, Ondrey FG et al. Contribution of conventional axial computed tomography(nonhelical), in conjunction with panoramic tomography(zonography), in evaluating mandibular fractures. Ann Plastic Surg 2000; 45: 415–421

17. Epstein JB, Caldwell J, Black G. The utility of panoramic imaging of the temporomandibular joint in patients with temporomandibular disorders. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 2001; 92:236–239

18. Brooks SL, Brand JW, Gibbs SJ, Hollender L, Lurie AG, Omnell KA et al. Imaging of the temporomandibular joint. A position paper of the American Academy of Oral and Maxillofacial Radiology Oral Surg Oral Med Oral Pathol Oral Radiol Endod 1997; 83: 609–618

19. Vasquuez L, Saulacic N, Belser U, Bernard JP. Efficacy of panoramic radiographs in the preoperative planning of posterior mandibular implants: a prospective clinical study of 1527 consecutively treated patients. Clin Oral Implants Res 2008:19:81–5

20. EAO. A consensus workshop organized by the European Association for Osseointegration in the Medical University of Warsaw, Poland. Clin Oral Implants Res 2012; 23: 1243–53
